Solis S5-GR3P20K 20kW Three Phase ON-Grid Solar Inverter
- Brand: Solis
- Product Code: 015266
- Availability: In Stock
৳173,130/-
Solis S5-GR3P20K 20kW Three Phase ON-Grid Solar Inverter
The Solis S5-GR3P20K 20kW Three-Phase On-Grid Solar Inverter delivers efficient solar power conversion for commercial and industrial installations. With a maximum efficiency of 98.7%, this solar inverter converts DC electricity from solar panels into usable AC power. Its 20 kW rated output supports three-phase grid-connected systems. The transformerless design contributes to efficient operation, while the compact structure simplifies installation. An LCD display provides system information, and app control enables convenient performance monitoring.
Designed for high-capacity solar installations, the Solis S5-GR3P20K supports a recommended maximum PV input power of 30 kW. This 20 kW solar inverter features a maximum DC input voltage of 1100 V and a wide MPPT voltage range of 160–1000 V. Two MPPT trackers support up to four input strings, helping optimize energy collection across different panel configurations. Its greater than 150% DC-to-AC ratio supports suitable system sizing for improved solar energy utilization.
For grid-connected applications, the Solis S5-GR3P20K operates as an On-Grid solar inverter with a rated grid voltage of 220/380 V or 230/400 V. It supports 50 Hz and 60 Hz frequencies, with a power factor above 0.99 under specified conditions. Total harmonic distortion remains below 2%, supporting high-quality AC output. Export power control also helps manage electricity fed into the grid according to system requirements.
Safety and durability remain key features of the Solis S5-GR3P20K three-phase solar inverter. Its IP66-rated enclosure supports outdoor installation, while integrated AFCI 2.0 helps detect arc faults. Additional protections include reverse polarity, short circuits, overcurrent, surges, overheating, and anti-islanding. Operating temperatures range from -25°C to +60°C. Weighing approximately 18 kg, this 20 kW solar inverter offers efficient power conversion and advanced monitoring for commercial solar energy systems.
Buy Solis S5-GR3P20K 20kW Solar Inverter from Brotherhood IT
In Bangladesh, you can get original Solis S5-GR3P20K 20kW Solar Inverter From Brotherhood IT. We have a large collection of latest Inverter to purchase. Order online from bhits.com.bd and get yours at the best price with delivery across Bangladesh. Solis S5-GR3P20K 20kW Solar Inverter comes with 5 Year warranty.
Specification
| General Information | ||
| Rated AC Output Power | 20kW | |
| App Control | Yes | |
| Protection | DC reverse-polarity protection Short circuit protection Output over current protection Insulation resistance monitoring Residual current detection Surge protection Grid monitoring Anti-islanding protection Temperature protection Multi peak scan Integrated AFCI 2.0 Integrated DC switch |
|
| Noise Level | < 30 dB(A) | |
| Others | Topology: Transformerless Supports export power control > 150% DC/AC ratio Display: LCD THDi: < 2% DC injection current: < 0.5% In |
|
| Output | ||
| AC Output | Max. output power: 20 kW Max. apparent output power: 22 kVA Rated grid voltage: 3/N/PE, 220 V / 380 V, 230 V / 400 V Rated grid frequency: 50 Hz / 60 Hz Power Factor: >0.99 (0.8 leading - 0.8 lagging) THDi: <2% DC injection current : < 0.5% In |
|
| Input (Charging) | ||
| DC Input | Recommended max. PV power: 30 kW Max. input voltage: 1100 V Rated voltage: 600 V Start-up voltage: 180 V MPPT voltage range: 160 - 1000 V Max. input current: 32 A / 32 A Max. short-circuit current: 40 A / 40 A MPPT number / Max. input strings number: 2/4 |
|
| Solar Input | Yes Recommended max. PV power: 30 kW |
|
| Environment | ||
| Operating Temperature | -25°C to +60°C | |
| Physical Information | ||
| Color | White | |
| Dimension | 310 × 563 × 219 mm | |
| Weight | Approx. 18 kg | |
| Warranty Information | ||
| Warranty | 5 Year Warranty | |
