Growatt SPF 5000 ES 5kW Hybrid Solar Inverter
- Brand: Others
- Product Code: 015504
- Availability: In Stock
৳49,500/-
Growatt SPF 5000 ES 5kW Hybrid Solar Inverter
The Growatt SPF 5000 ES 5kW Hybrid Solar Inverter is designed for off-grid solar power systems requiring efficient energy conversion. This Off-Grid Solar Inverter delivers 5kW rated output power with a maximum efficiency of 93%. Its single-phase hybrid design supports solar energy utilization in residential and remote applications. The inverter provides pure sine wave AC output, ensuring stable power delivery to compatible electrical appliances. Its compact construction measures 330 × 485 × 135mm and weighs approximately 12kg.
Equipped with an MPPT charge controller, the Growatt SPF 5000 ES Hybrid Solar Inverter optimizes solar energy harvesting across varying operating conditions. It supports a recommended maximum PV array capacity of 6kW. The MPPT operating voltage range spans 120-430VDC, with a maximum open-circuit voltage of 450VDC. Its solar input supports up to 100A charging current, helping manage energy collection and battery charging efficiently. These specifications make this MPPT solar inverter suitable for compatible solar installations.
For energy storage flexibility, the Growatt SPF 5000 ES 5kW Solar Inverter supports both lithium and lead-acid batteries. Its 48VDC battery system works with scheduled charging and discharging functions for improved energy management. The inverter delivers 220V or 230V AC output in battery mode, with a surge capacity of 10,000VA. An 80A AC charger supports grid or generator charging at 230VAC. Its UPS transfer time is typically 10 milliseconds, reaching a maximum of 20 milliseconds.
Designed for expandable solar installations, the Growatt SPF 5000 ES Hybrid Solar Inverter supports parallel connection of up to six units. This capability allows users to increase system capacity when requirements grow. The unit operates within temperatures ranging from -25°C to +60°C. Its maximum PV input voltage is 430VDC under the specified operating conditions, while the maximum PV input current reaches 100A. With off-grid functionality, battery compatibility, and solar charging control, this 5kW Solar Inverter supports efficient energy management for homes and remote power systems.
Buy Growatt SPF 5000 ES 5kW Hybrid Solar Inverter from Brotherhood IT
In Bangladesh, you can get original Growatt SPF 5000 ES 5kW Hybrid Solar Inverter From Brotherhood IT. We have a large collection of latest Solar Inverter to purchase. Order online from bhits.com.bd and get yours at the best price with delivery across Bangladesh. The Growatt SPF 5000 ES 5kW Hybrid Solar Inverter comes with 2 Year warranty.
Specification
| General Information | ||
| Battery Type | Supports Lithium/Lead-acid | |
| Rated AC Output Power | Voltage 48VDC | |
| UPS Transfer Time | 10ms typical, 20ms Max | |
| Output | ||
| AC Output | Output AC (Inverter) Rated output power: 5 kW Rated voltage battery mode: 220 V / 230 V Surge power: 10000VA Parallel Capability: 6 units max |
|
| Output Waveform | Pure Sine Wave | |
| Input (Charging) | ||
| AC Input | Input(AC Charger) Charge Current: 80A Voltage: 230VAC |
|
| Solar Input | Input (PV Side) Recommended max. PV array size: 6 kW MPPT Operating voltage Range: 120-430VDC Max. open-circuit voltage: 450VDC Max. Solar Charge Current: 100A |
|
| Environment | ||
| Operating Temperature | -25°C to +60°C | |
| Physical Information | ||
| Color | White | |
| Dimension | 330×485×135mm | |
| Weight | Approx. 12 kg | |
| Warranty Information | ||
| Warranty | 2 Year Warranty | |
